Since its found,ZERRU has sold ten thousand sets of porous metal elements filter housings, one hundred thousand pieces of sintered porous metal filter elements; the core filtering media of porous metal elements filter is developed by using the latest technology ; filtration precision could be up to 0.5μm-5μm, it is suitable for a variety of complex conditions.
Porous metal element filter system also is good for filtering high temperature、high pressure and high solids material; filter elements cleaning method could adopt backwashing, blasting, ultrasonic, which can achieve continuous automatic operation, avoid frequent manual cleaning and unnecessary parking; and max reduce environment pollution from filter materials and residue.
Technical parameters
| Shell material | Carbon Steel | SS304、321、316L、2507 | Incoloy、C276 and etc |
| Design pressure | 0.1~5.0Mpa | 0.1~5.0Mpa | 0.1~5.0Mpa |
| Design temperature | -196~400℃ | -196~500℃ | -196~1000℃ |
| Filtration precision(liquid) | 1~10μm | 1~10μm | 1~10μm |
| Cleaning method | Manual or Automatic |
1、The unique cleaning procedure: with core elements and cleaning procedures,the cleaning effect is equivalent to more than 80% of the initial state. Greatly extending filter life cycle, while reducing
pollutant emissions by 72%.
2、Excellent filtration components, porous metal elements, this type of filter element have good regeneration
purpose and not require frequent replacement.
3、
Zerru Filter uses a unique process to sinter stainless steel powder with high strength and opening rate, filtration efficiency could be up to 1 micron 99%.
4、Fully enclosed structure, 100% automatic, for a variety of complex and require explosion-proof of occasions.
INOCO micro porous metal element filter is equipped with a variety of pneumatic or electric valves to achieve
filtration and cleaning process automatically and reduce manual cleaning and the potential safety hazards and increase productivity.
5、A wide range of elements sizes and materials ZERRU can offer from 10mm ~ 200mm diameter powder sintered element, and the material includes 304L, 316L, Monel, Hastelloy.
