Basket Strainer Perforated Basket Filter

Product Description Structure (for Basket Strainer)

1. Headline & Key Benefits (The Hook)
Protect your valuable equipment from pipeline debris with our industrial Basket Strainers. Engineered for reliability and easy maintenance, they provide efficient coarse filtration to extend the life of pumps, valves, and meters. Choose from simplex for standard duty or duplex for continuous processes.

2. Overview & Introduction
Our Basket Strainer is a robust, in-line filtration device designed to remove large solid contaminants from liquid flows. Featuring a simple yet effective design with a removable perforated basket, it is the most cost-effective first line of defense in any industrial piping system. Available in single-basket (simplex) and twin-basket (duplex) configurations to meet various operational needs.

3. Key Features & Advantages (Bullet Points – Scannable)

• Dual Configuration Options: Simplex models for applications with planned downtime; Duplex models for 24/7 continuous operation with changeover valves.

• High-Duty Construction: Cast or fabricated body in carbon steel, stainless steel (304/316), or other alloys. Sturdy perforated basket withstands high differential pressure.

• Optimized Hydraulics: Large basket surface area ensures minimal pressure drop and maintains system flow efficiency.

• Easy to Service: Bolted or hinged cover allows quick access. Basket is fully removable for manual cleaning, inspection, or replacement—no disposable cartridges needed.

• Wide Compatibility: Standard flanged connections (ANSI, DIN, JIS) available in sizes from 1" to 24".

• Clear Maintenance Signaling: Optional pressure gauges or differential pressure indicators show when cleaning is required.

• Customizable Filtration: Variety of perforation sizes (e.g., 1mm, 3mm, 1/4") and mesh screens to meet specific straining requirements.

4. Technical Specifications (Table Format is Ideal)





Parameter	Specification
Type	Simplex Basket Strainer / Duplex Basket Strainer
Design Standard	ASME B16.34, ANSI B16.5, DIN, JIS
Body Material	Carbon Steel (WCB), Stainless Steel 304/316, Duplex Steel, etc.
Basket Material	304/316 SS Perforated Plate or Wire Mesh
Straining Rating	500 to 5000 Microns (Customizable)
Design Pressure	Up to 300 PSI (Class 150, 300, 600 available)
Design Temperature	-20°F to 750°F (-29°C to 399°C), depends on seal material
Connection Type	RF Flanges, Threaded, Buttweld
Seal Material	EPDM, Nitrile, Viton, Grafoil, PTFE



5. Applications (Where It Is Used)
Essential for pipeline protection across numerous industries:

• Water Treatment: Raw water intake, cooling water systems, irrigation, pump suction protection.

• Oil, Gas & Petrochemical: Fuel oil pre-filtration, pipeline debris removal, produced water, refinery feed lines.

• Chemical Processing: Protecting centrifugal pumps, heat exchangers, and spray nozzles from pipe scale.

• Power Generation: Condensate and feedwater systems, turbine lube oil pre-straining.

• Marine & Offshore: Sea Water Filtration, ballast water treatment, engine cooling loops.

• General Industry: Hydraulic line protection, process water, CIP (Clean-in-Place) systems.
