ZMC-D Double Magnetic Easy Clean Filter

Our high-strength magnetism is easy to clean.

Embedded grid provides unparalleled horizontal pollutant removal, removing submicron iron and quasi magnetism from the most demanding and challenging process environment. The ZMC-D Magnetic easy clean filter - Double is designed to excel in such conditions. This unit contains a high-strength magnetic grille that is easy to clean, a feature also found in the Magnetic Drawer-In-Housings. The grille is produced around a food-grade seal by a three-cone locking nut that ensures uniform pressure, which is a characteristic shared by the High Intensity Magnetic Grid Separator and Magnetic Drawer Separators.

It is common to install many units throughout the entire processing facility to ensure that pollutants are removed at the source of generation. The ZMC-D Magnetic easy clean filter - Double, along with other models like the Magnetic Drawer-In-Housings, are often used for this purpose. All dry powder and granular materials can be processed through this unit. Electrical safety interlocks can be installed on the grid to stop the process unexpectedly opened, which is a safety feature that is integral to the design of the ZMC-D Magnetic easy clean filter - Double and other separators such as the High Intensity Magnetic Grid Separator and Magnetic Drawer Separators.

Benefits

• Easy to clean
• Removes micron-sized contaminants
• High collection capacity
• Reduces 'spark' risk

Performance

Magnetic Performance: 7000, 9000, 10000

Performance Reading On Tube Surface: Magnet Grade N35 & N45 – Inspected and confirmed via hysterograph prior to use

Temperature: -20°C / +90°C

Pressure: ± 0.2 Bar

Suitability

Suitable Products: Dry powders and granulates

Suitable Location: Inlet / outlet points, pre-/post-silo and machinery points

Materials

Magnetic Material: Rare Earth Neodymium Iron Boron - (NdFeB)

Housing: 316 grade stainless steel

Tubing: 316 grade stainless steel

Sealing: Self-adhered white foam

Tri-cone Nuts: Stainless Steel

Surface Finish: Brushed internally / polished externally to 0.6μm

Cleaning

When the unit requires cleaning, simply remove the outer grid securing tri-cone locking nuts and remove the grid from the housing. Remove the central tri-cone locking nut and separate the grid assembly allowing all attracted contamination to simply fall away.

Options

• Stainless Steel Toggle Clamps
• Larger sizes available
• Pharmaceutical specification
• Safety relay switches
• Metal Detectable Seal
• Higher temperature versions available
