Methanol Precision Filter

Product Overview

Wuxi ZERRU Technology Co., Ltd. presents the Methanol Precision Filter, specifically designed for methanol (CH₃OH) production, storage, transfer, and recovery applications.
Given methanol’s characteristics — high volatility, strong hygroscopicity, sensitivity to moisture, and potential presence of mechanical impurities or by‑products — this filter utilizes high‑performance filtration media and sealing systems to ensure methanol purity, protect downstream equipment (reactors, pumps, valves, flow meters), and enhance final product quality.

Key Advantages

1. High‑precision Contaminant Removal

   • Filtration rating from 0.5 to 200 microns – effectively removes catalyst fines, rust, weld slag, polymer particles, and other solid contaminants from methanol.

2. Leak‑proof Sealing Design

   • Low‑permeability sealing materials (PTFE, modified PTFE, flexible graphite) compatible with methanol’s low surface tension – prevents leakage and solvent attack.

3. Corrosion‑resistant All‑Stainless Steel Construction

   • Housing and filter basket in SS304 / SS316L – pickled and passivated surface finish – withstands mild corrosiveness of methanol without secondary contamination.

4. High Flow Rate with Low Pressure Drop

   • Optimized inlet/outlet geometry and basket open area – single‑unit capacity from 5 to 500 m³/h with pressure drop typically below 0.05 MPa – reduces pump energy consumption.

5. Quick‑open Design for Easy Maintenance

   • Eye bolt or quick‑release clamp design – allows fast basket or cartridge change without special tools – ideal for frequent operations such as methanol tank farm or truck loading/unloading.

6. Optional Nitrogen Purge Port

   • Equipped with N₂ purge/drain connection – facilitates safe draining of residual methanol, protects maintenance personnel, and minimizes volatile losses.

Technical Specifications





Parameter	Typical Value
Nominal Diameter	DN25 – DN300 (1” – 12”)
Design Pressure	1.0 – 2.5 MPa (higher on request)
Design Temperature	-20°C to +150°C
Filtration Rating	0.5 – 200 microns
Housing Material	SS304 / SS316L
Filter Media Material	Stainless steel sintered mesh / pleated cartridge
Seal Material	PTFE / Modified PTFE / Flexible graphite
Connection Type	Flanged (HG/T 20592, ANSI, DIN, etc.)
Surface Finish	Pickling & passivation / Mechanical polishing
Optional Features	Differential pressure gauge / Vent valve / Drain valve / N₂ purge port



Typical Applications

• Methanol production units (crude methanol filtration before distillation)

• Methanol storage tanks & tank farms (truck / railcar loading/unloading)

• Methanol fuel systems (boilers, marine or industrial engines)

• Chemical synthesis processes (formaldehyde, acetic acid, MTBE, DME, etc.)

• Pharmaceutical & solvent recovery systems

---

Why Choose ZERRU Technology?

• Specialized in methanol applications – deep understanding of methanol’s physical/chemical properties.

• Custom engineering – designs available for high pressure, low temperature, or explosion‑proof areas.

• Fast delivery – standard models in stock; custom orders in 7–15 days.

• Global certifications – ISO 9001, CE, and optional pressure vessel (ASME, GB/T 150).



Ordering Information

For an accurate quotation, please provide:

1. Methanol concentration & impurities (e.g., water content, solid type)

2. Filtration rating required (microns)

3. Flow rate (m³/h) & operating pressure

4. Connection standard (HG, ANSI, DIN, etc.)

5. Whether N₂ purge, jacketed heating, or explosion‑proof design is needed
